ZD221, WSM
ROTARY MOWER
[2] LIFTING MECHANISM (1 )
(2)
(3)
(4)
(5)
(6)
3GZAAAIMP002A (1) Lift Cylinder (2) Rear Arm
(3) Horizon Plate (4) Lift Shaft
(5) Front Arm
(6) Hydraulic Lift Control Pedal
The lifting of mower is performed by the hydraulic system on the machine. For avoiding danger, the mower should be kept lifting when traveling. When the hydraulic lift control pedal (6) is moved to "UP" position, the rear arms (2) are risen with lift shaft (4) by the oil pressure of hydraulic system. Therefore, front arms (5) connected with the horizon plates (3) are lifted at the same time. As this link system is a parallel linkage, the mower can be kept parallel at every position.
A
CAUTION • Never operate mower in transport position.
6-M2
