LIFTING MECHANISM

3GZAAAIMP002A

(1) Lift Cylinder

(3) Horizon Plate (5) Front Arm

(6) Hydraulic Lift Control Pedal (2) Rear Arm (4) Lift Shaft

The lifting of mower is performed by the hydraulic system on the machine. For avoiding danger, the mower should be kept lifting when traveling. When the hydraulic lift control pedal (6) is moved to "UP" position, the rear arms (2) are risen with lift shaft (4) by the oil pressure of hydraulic system. Therefore, front arms (5) connected with the horizon plates (3) are lifted at the same time. As this link system is a parallel linkage, the mower can be kept parallel at every position.

A Caution

• Never operate mower in transport position.
