ZD221 , WSM
FRONT AXLE
3. CHECKING, DISASSEMBLING AND SERVICING [1] DISASSEMBLING AND ASSEMBLING (1) Separating Front Wheel and Wheel Bracket Remove the front Wheel 1. Inspect all parts for wear or damage. Replace the parts as needed. (When reassembling) • Apply grease to grease fittings (6). (See page G-24.) Tightening torque
(1) Spacer (2) Oil Seal (3) Thrust Ball Bearing (4) Locking Nut
3GZAAAD6P002A
Front wheel mounting bolt and locking nut
20 to 25 N'm 2.1 to 2.5 kgf.m 15 to 1SIbHt
(5) Hex. Bolt (6) Grease Fitting (7) Sleeve W1010912
Remove the Wheel Bracket 1. Remove the wheel cap (1 ). 2. Remove the lock nut (2) and wheel bracket (6). 3. Inspect all parts for wear or damage. Replace the parts as needed. (When reassembling) • Do not mistake the direction when reassembling the plate spring (3), bearings (4) and oil seal (5). ~--(5)
Tightening torque
(1) Wheel Cup (2) Lock Nut (3) Plate Spring (4) Bearing
(7)
Locking nut tightening torque
70to SO N'm 7.2 to S.1 kgf·m 52 to 591bHt
(5) Oil Seal (6) Wheel Bracket (7) Grease Fitting W1011142
3GZAAAI6P002A (1 ) (2)
i---(3) (4) F!..;t---
(5) (6)
3-S3
