C - SWITCH FOR ALIGNMENT OF THE WHEELS
CT6-18 with Loader-Type Controls LIFTING A LOAD - Pull lever A rearward to raise the boom. - Push lever A forward to lower the boom. TILTING THE CARRIAGE - Move lever A to the left for rearward tilt. - Move lever A to the right for forward tilt. TELESCOPING THE BOOM - Push lever B forward to extend the boom. - Pull lever B rearward to retract the boom. ATTACHMENT OPERATION - Move lever C forward or rearward to actuate a hydraulic attachment.
A A3
A1
A2
B1 C
B B2
This switch enables alignment of the wheels. The indicator lamp indicates if it is ON. WHEEL ALIGNMENT PROCEDURE
B
- Press the switch (signal lamp ON).
C
A
- Shift the hydraulic valve control lever for steering selection A to position A2 (4-wheel steering). D
- Turn the steering wheel and bring the rear wheels into alignment until the lamp B2 is ON. - Shift the hydraulic valve control lever for steering selection A to position A1 (highway use). - Turn the steering wheel and bring the front wheels into alignment until the lamp B1 is ON.
TRANSMISSION CUT-OFF - Press button D (see: chapter 5 - INSTRUMENTS AND CONTROLS: 5 - SWITCH PANEL).
WARNING
CT6-18 with “Pick-N-Place” Controls
Before driving on roads, it is necessary to check the alignment of the rear wheels and to select front-wheel steering mode. The alignment of the rear wheels must be done regularly while driving the telescopic handler, with the help of the green lamps. In case of problems, consult your dealer.
LIFTING A LOAD - Pull lever A rearward to raise the boom. - Push lever A forward to lower the boom. TELESCOPING THE BOOM - Move lever A to the left to retract the boom. - Move lever A to the right to extend the boom. TILTING THE CARRIAGE - Push lever B forward to tilt the carriage forward. - Pull lever B backward to tilt the carriage rearward. ATTACHMENT OPERATION - Move lever C forward or rearward to actuate a hydraulic attachment. TRANSMISSION CUT-OFF - Press button D (see: chapter 5 - INSTRUMENTS AND CONTROLS: 5 - SWITCH PANEL).
20 - HYDRAULIC CONTROLS AND TRANSMISSION CUT-OFF IMPORTANT: Do not attempt to alter the hydraulic system pressure by adjusting the pressure regulating valve. In the event of suspected malfunction, contact your dealer. ANY ALTERATION MAY VOID THE WARRANTY.
WARNING Use the hydraulic controls carefully without jerking, to avoid accidents caused by sudden movement of the telescopic handler.
