ASSEMBLY INSTRUCTIONS (Continued) LEVEL BASE Place a level on the top of the traverse base and check the unit for level side to side. Adjust the leveling feet as necessary until the machine is level. See FIG. 3 . Now place the level across the traverse base from front to rear. Adjust the leveling feet as necessary until the machine is level. See FIG. 3 .
LOOSEN JAM NUT TO ADJUST FOOT LEVELING FEET LOCATED AT CORNERS OF MAHCINE
When both front to back and side to side leveling procedures have been completed, thread the hex jam nuts up against the nut that is welded to the bottom of the machine. Be careful not to move the leveling feet when tightening the jam nut. See FIG. 3. Make certain that all four leveling feet are firmly contacting the floor.
FIG. 3
Recheck that the machine is level after locking the four feet into position.
Remove the carton and remove the contents from the carton onto a workbench. The carton includes:
Product Packet Assembly (Operators & Service Manuals)
Coolant Concentrate (Pint)
Grinding Wheel Wrench
9
