BI620123
Service Manual
SERVICING AIR INTAKE SYSTEM As with other maintenance and examination schedules the flameproof intake system should be inspected, by a suitably appointed and qualified person, at intervals consistent with mine site and statutory maintenance schemes. The following is the suggested intervals for maintenance and inspection of the flameproof air intake components. Daily or every 10 service hours: Visually check joint fasteners (nuts, bolts and studs) securing flameproof joints i.e. flame trap flange to aftercooler, aftercooler to cylinder head.
Refer to the Diesel Engine System approval drawings for flame path dimensions and conditions.
Intake Clamps and Rubber Boots
AIR CLEANER ASSEMBLY
INDICATOR ASSEMBLY
AIR INTAKE SYSTEM
Rev. 0
FBL-10 LHD/Utility Serial No. 80042
137
