Service Manual
SPECIFICATIONS All specifications are subject to change without notice. Always Axles consult BUCYRUS to obtain current information before Type Front axle make/model applying critical loads. Rear axle make/model Differential type Capacities Differential lock type - front Bucket Payload 8000 kg Differential lock type - rear RAS Forks, Max Payload 10000 kg Overall ratio RAS Slewing Jib, Max Payload 7000 kg RAS Belt / Cable Reeler, Max Payload 7000 kg Wheels Maximum un-braked trailer mass 10000 kg Make/model Maximum braked trailer mass Consult BUCYRUS Standard Ejector Bucket Heaped capacity (SAE) Struck capacity Break out force standard bucket tip (hydraulic) Tractive effort, Maximum Bucket Motion Times Lift to full raised position Lower fully to floor Roll bucket fully back Roll bucket fully forward
7.0 sec 4.0 sec 7.0 sec 5.0 sec
Weight Unladen with full tanks and bucket Laden with forks and 10T load Engine Type Cooling system Cooling fan Engine make/model Displacement Maximum power Maximum torque
3.5 m3 2.7 m3 15000 kg 21300 kg
19000 kg 29000 kg
Tyres - Standard Type Size Ply rating Inflation media Inflation pressure
3 piece (heavy duty) Michelin X mine D2 17.5 x 25 Radial Air 110 psi front, 110 psi rear
Hydraulic Systems Steering Closed centre, pressure compensated 2500 psi Brakes Closed centre, pressure compensated 2500 psi Bucket/lift Open centre 3000 psi PTO (2 on machine) Open centre 3000 psi Tank type Sealed and pressurised Tank pressure 10 psi Hydraulic Filtration Hydraulics return
Diesel, turbocharged, and 4 cycle Water based radiator Hydraulic driven fan Caterpillar 3126 7.2 litre 172 kW @ 2200 RPM 720 Nm @ 1400 RPM
Outboard planetary Dana/Spicer 16D Dana/Spicer 16D Bevel gear and pinion Posi-Torque Posi-Torque 31.06:1
Return 25 micron replaceable with bypass Pressure10 micron replaceable with bypass In line, 25 micron
Steer/brake system Optional return PTO
Main Hydraulic Pump Type Standard pump output @ 2600 RPM
Gear Open centre 161.2 lpm
Engine Speeds Low idle High idle Governed
700 RPM 2600 RPM 2100 RPM
Steering/Brake Pump Type Pressure compensated piston Standard pump output @ 2600 RPM 117 lpm
Stall Speeds Converter stall Full stall Hydraulic stall
2100 RPM 1700 RPM 2050 RPM
Cylinders Type Rods Counterbalance valves Cushion stops
Double acting Case hardened and hard chromed Lift and tilt Steering and tilt
Steering System Control valve Actuation Pressure compensated Cushion relief
Closed centre Orbital 2500 psi 3000 psi
Fuel Consumption At full power Average mine duty Start System Starter motor type Intake Air Cleaner Type/make Dual element type Exhaust Conditioner Type Make Exhaust Flame trap After treatment
37.5 litre/hr 8-30 litre/hr Air (Auststart) Dry/Donaldson Primary and secondary
Accumulator Steering Type Quantity x capacity Operating pre-charge pressure
Piston 1 x 5.7 litre 900 psi Nitrogen
Flameproof water bath conditioner BUCYRUS Fitted Catalytic exhaust purifier
Accumulator Brakes Type Quantity x capacity Operating pre-charge pressure
Piston 1 x 1.96 litre 900 psi Nitrogen
Transmission Type Power shift with forward/reverse modulation Make/model Dana/Spicer 32000 series MHR Speeds, forward and reverse 4
Bucket System Control valve Actuation Main relief
Open centre Remote hydraulic pilot 3000 psi
Torque Converter Type Mounted in transmission, Single element Make/model Dana/Spicer 13.1 integral
6
