BI619954
Edition 03.2009
Maintenance
4 x I4 - the same activities as I3 and 2 x I4 as well as in addition No.
Component
Maintenance work
Cross-reference
1
Cooling system
Check all of the hoses and hose connections for leaks and to ensure that they are not porous, if required, replace them
Refer to Chapter 6.14
2
DCC
Check all of the painted surfaces of the DCC for damage, repair any damaged paint surface
Refer to Chapter 6.15
3
Maintenance covers
Replace the seals at the maintenance covers
Refer to Chapter 6.16
R3– overhaul 2 No. 1
Component DCU fans
Maintenance work Replace the fans
Cross-reference SIBAS equipment manual
Note The special tools, operating and other materials that are required are now subsequently listed. Ordering data and suppliers for the special tools, operating and other materials are listed in Chapter 8.1.
6.3
Visually checking and cleaning the heat exchanger (E02)
The heat exchanger should be visually checked for accumulated dirt (pollution). If dirt is found then it should be removed as follows: •
Use an industrial vacuum cleaner to remove coarse dirt from the air intake side
•
Use service cover on ventilation channel to remove fine dust by blowing it out with compressed air from blower side (dry, free of grease). The compressed air should be lightly swept over the cooler (do not concentrate just on one point) and must be in parallel with the fins so that they are not damaged. The maximum pressure of the compressed air may not exceed 8 bar.
At longer intervals (approx. R2 - overhaul), it may be necessary to clean using water. The following points should be carefully observed: •
Clean with water preferably with the main blower removed
•
Use high-pressure cleaner for cleaning with a maximum pressure of 50 bar.
Siemens Ltd. A5E01511750J/ 4M-2601-1645240 AC
Shovel 295HD/ HR DCC Operation & Maintenance Manual
77
