OPERATING INSTRUCTIONS 6030, 6030FS Operation
Assemblies resp. Measuring device reservoirs Cooling system reservoir
Remarks
Level indicator (4, Fig. 2-82:) Fill in cooling fluid using express couplings (2 and/or 3, Fig. 2-85:). Stop filling when the level indicator indicates maximum filling level. (see: chapter "Cooling system Cooling liquid").
Grease container BCS display (Fig. 2-83:) – cental lubricating system
BCS gives a warning if the grease container is nearly empty. Switch on the display system (optional) with the toggle switch (23), indicator lamp (22) comes on. Fill in grease using express coupling (11, Fig. 2-84:). Stop filling when the grease container is full, the indicator lamp (34) lights up. On completion of filling, switch the display system off again with the toggle switch (23), indicator lamp (22) is off.
Fig. 2-82:
Fig. 2-84:
Fig. 2-85: Fig. 2-83:
2-66
BA RH120E(3 725 097.01)-EN
