OPERATING INSTRUCTIONS 6030, 6030FS Operation Assemblies resp. Measuring device reservoirs
Remarks
Pump transfer gearboxes
Dipstick (1, Fig. 2-75:)
Fill in gear oil using express couplings (4 and 5, Fig. 2-76:). Stop filling when the oil reaches the "max" mark on the dipstick (see: Part 3, chapter "Pump transfer gearbox Checking the gearbox oil level/Filling in oil").
Engines
Dipstick (1, Fig. 2-77:)
Fill in engine oil using express couplings (8 and 9, Fig. 2-78:). Stop filling when the oil reaches the "max" mark on the dipstick (see: chapter "Engine - engine oil level/filling in oil").
Engine oil tank (option)
Monitoring lamps (1 and 2, Fig. 2-78:)
Fill in engine oil using express couplings (6 and 7, Fig. 2-78:). Stop filling when monitoring lamps (1 and / or 2) lit up, (see: chapter "Engine , filling in oil").
Fig. 2-75:
Fig. 2-77:
Fig. 2-78: Fig. 2-76:
