OPERATING INSTRUCTIONS 6030, 6030FS Operation
Assemblies resp. Measuring device reservoirs
Remarks
Fuel tank
Switch on the monitoring system by using toggle switch (23, Fig. 2-74:). The indicator light (22) comes on.
BCS fuel indicator (Fig. 2-73:)
Fill in fuel using express coupling (1). The indicator light (32) comes on when the LH fuel tank is full. Stop filling when the fuel tank is full. The indicator light (33) comes on when the RH fuel tank is full. Stop filling when the fuel tank is full. Switch off the monitoring system by using toggle switch (23), indicator light (22) is off.
Fig. 2-74: Fig. 2-73:
BA RH120E(3 725 097.01)-EN
2-63
