OPERATING INSTRUCTIONS 6030, 6030FS Operation Filling in fuel
Service station (tanklift) The excavator is equipped with a central service station (Fig. 2-69: resp. Fig. 2-70:) for refuelling. The service station is attached to the frame and accessible from the ground below the uppercarriage.
Fig. 2-67:
Unscrew cap of filler tube (1, Fig. 2-67:). Fill in fuel through the filter sieve in the filler tube. Do not remove the sieve! A micro filter in the filling line is recommended.
Fig. 2-69:
Fuel can also be filled in using the service station (tanklift), see the following chapter "Service station (tanklift), Fuel Tank".
Back-up heating (option), filling in fuel The fuel reservoir for the back-up heating system is located in the module below the driver’s cab (Fig. 2-68:). Fill in clean fuel through the filler neck. Fig. 2-70:
Fig. 2-68:
BA RH120E(3 725 097.01)-EN
2-61
