OPERATING INSTRUCTIONS 6030, 6030FS Operation (Fig. 2-62:) No. Element 101 Push-button
(Free for options)
Function Symbol Can be used as a push-to-speak button on a radio, or to switch over from one camera to another one, or to switch on / off the water spraying system. Button is pressed: The stick cylinders are pressurized on retracting. Press button (102) only in position "0" of control lever (115).
102 Push-button
Stick floating position (shovel equipment only)
103 Push-button
Boom floating position
Button is pressed: The boom cylinders are pressurized on retracting. Press button (103) only in position "0" of control lever (116).
104 Push-button
Warning signal
105 Push-button inside the seat
Electronic excavator control (servocontrol)
111 Pedal 112 Pedal
Shovel trap (shovel equipment only) Travel, left track
113 Pedal
Travel, right track
Button is pressed: Acoustic warning signal / horn is activated. The electronic excavator control (servocontrol) is activated when the drivers sits down on the seat. The electronic excavator control (servocontrol) is deactivated when he leaves the seat. Forwards – shovel trap is opened; Backwards – shovel trap is closed. Forwards – forward travel Backwards – backward travel. Forwards – forward travel; Backwards – backward travel.
114 Footrest 115 Control lever
116 Control lever
117 Push-button 118 Thumb wheel
119 Push-button
Shovel trap (shovel equipment only)
By-pass for the automatically switch off for stickand /or backhoe cylinders (Option)
120 Thumb wheel
BA RH120E(3 725 097.01)-EN
Forwards – raising the stick Backwards – lowering the stick. To the left / right – slewing and braking of the superstructure. Forwards – lowering the boom; Backwards – raising the boom. To the left – backwards tipping of shovel / bucket; To the right – dumping of shovel / bucket. Not used on this machine. Turn Forwards – shovel trap is opened; Turn Backwards – shovel trap is closed. Function can be overridden by Pedal 111. (Thumb wheel is spring centered). Lower half pushed – automatically stopped stick- and/or backhoe cylinders can be driven slowly to the limit stopps. Upper half pushed – Each press on the button increments the loaded dumper count for by "1". (Count reset with button (91)). Not used on this machine.
2-51
