OPERATING INSTRUCTIONS 6030, 6030FS Operation (Fig. 2-60:) All switches and pushbuttons have an illuminated symbol face. The opposite side is equipped with an LED. The LED lights up when the switch / pushbutton is actuated. Function
No.
Element
71
Switch
Servo-control
Press the switch face with the symbol: The electro-hydraulic servo-control is enabled.
72
Switch
Travelling speed
Not actuated: 1st travelling stage travelling forwards / backwards is possible
Symbol
Press the switch face with the symbol: 2nd travelling stage, only parallel forward travel is possible. in case of backward travel and cornering, the machine switches back automatically into the 1st travelling stage. Not connected.
73 74
Monitoring lamps
Engine oil interval prolongation
Not connected.
75 76
Lamp is lit up, when the right or the left pump of the prolongation system is running.
Push-button
When the machine has to be manoeuvered out of dangerous situations
Press the switch face with the symbol: The machine can be driven and the superstructure be slewed although these functions are automatically deactivated. Use this function only in dangerous situations to manouever yourself or the machine out of hazard zones. Risk of damaging parts of the machine, e.g. the hydraulic ladder or the tanklift.
81
Switch
Floodlamps
Switches the floodlamps on the driver´s cab on and off.
82
Switch
Floodlamps
Switches the floodlamps on the hydraulic oil cooler module on and off.
83
Switch
Floodlamps
Switches the floodlamps on the cab module on and off.
84
Switch
Floodlamps
Switches the floodlamps on the boomon and off.
85
Switch
Floodlamps rear
Switches the floodlamps on the counterweight on and off.
86
Switch
BA RH120E(3 725 097.01)-EN
Not connected.
