OPERATING INSTRUCTIONS 6030, 6030FS Operation (Fig. 2-55) BCS, Board Control System, display screen example (For further information please refer to section 5 of this Operating Instructions, chapter “Board-ControlSystem”). No.
Element
Function
1
Status line
Indicates activated functions and operating hours. The symbols displayed are those of the switches in the control column
2
Touch-screen Monitor
BCS
Indicates collected operating data graphically and / or numerically, displays warning messages, fault messages and – if needed – instructions for help.
3
Pushbutton
Navigation in menus
Control of cursor movements, program selection within the BCS, confirmation of inputs / displayed values (Enter), quitting of menus / sub-menus
4
Push-button
Numeric keypad
Input of numeric values.
5
Touch-screen buttons
Examples
6
Status line
Fault messages
BA RH120E(3 725 097.01)-EN
Symbol
Displays fault messages as a code number and as plain text. The "Fault" button permits displaying further fault messages stored in the system.
2-37
