OPERATING INSTRUCTIONS 6030, 6030FS Operation (Fig. 2-54:)
BCS, Board-Control-System No. 1
Element BCS
Function Electronic system for measured data acquisition and processing
Board Control System, acquisition and display of important operating data of the excavator.
The monitor displays collected operating data, warning messages and – if needed – instruction for help.
The surface of the monitor is sensitive to the touch (touch-screen technology). A touchscreen permits selecting menus and programs by touching graphic control symbols and to recall, for instance operating data of the excavator. For further information please refer to section 5 of this Operating Instructions, chapter “Board-Control-System”.
2
Monitor
BCS
3
Push-button
Navigation in menus Control of cursor movements, program selection within the BCS, confirmation of inputs / displayed values (Enter), quitting of menus / sub-menus
4
Push-button
Numeric keypad
BA RH120E(3 725 097.01)-EN
Symbol
Input of numeric values.
2-35
