OPERATING INSTRUCTIONS 6030, 6030FS Operation Reducing the operators exposure to vibrations Vibrations, oscillations and movements of the machine cannot be avoided when the machine is in operation. They also have an effect on the operator. These effects on the operator can however be avoided, if the driver's seat is adjusted correctly. Therefore, make use of the seat's various adjustment features (see Fig. 2-36: and Fig. 2-37:):
shock absorption (Absorber),
body weight setting (Weight adjustment),
horizontal movement damping (Fore/aft isolator).
Trainer's / instructor's seat For driver training / instructing purposes it is often required that a trainer / instructor accompanies the driver in the cab. For the safety of the trainer / instructor during excavator operation the cab is equipped with a second seat. This seat is installed behind the driver's seat (Fig. 2-38:). Sit down on this seat and do not forget to fasten the seat-belt (if installed). Do not leave this seat during the training / instruction session and /or as long as the machine is in operation.
Adjust the seat before beginning work to suit your personal requirements. Check whether all adjustments are functional. If this is not possible, have the seat checked and repaired as soon as possible.
Fig. 2-38:
BA RH120E(3 725 097.01)-EN
2-27
