OPERATING INSTRUCTIONS 6030, 6030FS Operation Shutting off the supply voltage (battery main switch) The supply voltage is shut off when either of the following switches (black / yellow) is depressed: the switch on the control column (31, Fig. 2-34:), the switch in the engine module (Fig. 2-35:).
This function shuts off the complete electrical system of the by disconnecting the two poles from the batteries (battery main switch). In this case, all engines are shut off and all valves are de-energized so that no working movements can be performed anymore. The power supply of the electronic control units of the engines (ECM) and of the machine (BCS, SPS) is shut off after a brief delay. The delay ensures that the current operating data can be saved and the systems shut down properly.
Fig. 2-34:
The machine can only be put back into operation when all switches listed above are again in their basic position (i.e. not actuated).
Fig. 2-35:
