OPERATING INSTRUCTIONS 6030, 6030FS Operation Folding ladder (optional) Raising resp. lowering the folding ladder (Fig. 2-18:).

Lowering the folding ladder (from the upper carriage)  Start engine.  Push lever (1, Fig. 2-19:)on control valve (2) downwards to position “ II “.

The folding ladder is lowered (Fig. 2-18:).

The folding ladder can also be lowered when the engine is stopped.

Fig. 2-18:

Raising the folding ladder (from the upper carriage)  Start engine.  Pull lever (1, Fig. 2-19:) on control valve (2) upwards to position “ I “.

The folding ladder is raised (Fig. 2-20:).

Fig. 2-20:

Lowering the folding ladder (from the bottom)  Pull down rope (3, Fig. 2-21:).

The folding ladder is lowered (Fig. 2-18:).

Fig. 2-19:

The upper carriage can only be swung when the folding ladder is raised completely (Fig. 2-20:).

BA RH120E(3 725 097.01)-EN

Fig. 2-21:

2-19
