OPERATING INSTRUCTIONS 6030, 6030FS Operation Entering and leaving the machine Safety instructions Risk of injury due to slipping.
Access ladder lighting The access ladder of the machine can be illuminated.
Clean off oil, grease, soil, mud, snow, ice and other substances from footwear, grab handles, ladders and steps.
From outside: The pull-switch (1, Fig. 2-12:) of the lighting system is located beneath the superstructure. The lights are switched on from the ground by means of the pull-rope (2).
Keep ladders, steps, platforms and grab handles in a non-slippery condition.
From the cab: The switch is located besides the door (arrow, Fig. 2-13:).
For entering and leaving use only the ladders, steps, platforms and grab handles provided (see: illustration in Fig. 2-11:).
The lighting remains on during a presettable ON time. The ON time of the lighting is factory-adjusted to three minutes.
Always face the machine when entering or leaving it.
Fig. 2-12:
Fig. 2-11:
Fig. 2-13:
BA RH120E(3 725 097.01)-EN
2-17
