BI017763
OPERATING INSTRUCTIONS 6030, 6030FS Introduction Noise emissions
Vibration data
Noise emission data are specified in acc. with EC Machine Directive 2006/42/EC, Annex I, Section 1.7.4.2.u)
On the condition that the excavator is used within the limits of its designated use, the installation of seats for drivers in conformity with ISO 7096 ensures that the weighted vibration accelerations awz (measured in compliance with ISO 2631 Part I) fulfill the requirements with respect to the protection against whole-body vibrations in acc. with EC Vibration Directive 2002/44/EG.
Sound power level: LWA = 114,9 dB(A). Sound pressure level at driver's seat: LpA = 78 dB(A).
The vibrations transferred are indicated in acc. with EC Machine Directive 2006/42/EG, Annex I; Section 3.6.3.1, resp. the "Lärm - und Vibrations-Arbeitsschutzverordnung" of 18.12.2008, Section 4. The effective value of the weighted acceleration to which the wole body is exposed, does not exceed 0.5 m/s2. The measurement uncertainty is ±3% (tolerance of the measuring instruments).
BA RH120E(3 725 097.01)-EN
1-7
