OPERATING INSTRUCTIONS 6030, 6030FS Inspection and servicing Loosen bolts (13, Fig. 3-83:) and take off spring clip (14) and disk (15). Remove basket (12) and clean in paraffin oil. Install basket (12). Insert filter element (9) together with sealing ring (11) and cap (8) with sealing ring (10).
Replace also the return-flow filter in the filter housing (cooling-system). The return-flow filters are located under the caps (10, Fig. 3-84:). (See: "Replacing the hydraulic oil return-flow filters (filter housing“).
Refit cover (3). Clean the magnetic rod. The magnetic rod is located under cap (19). If metal filings are detected, locate cause and rectify. Contact the CGM HMS Service, if required.
Fig. 3-84:
Fig. 3-83:
