OPERATING INSTRUCTIONS 6030, 6030FS Inspection and servicing Water trap (option) Water contained in the fuel is removed by the water trap (Fig. 3-49:).
Servicing Draining off water Carry out the following works in accordance with the servicing schedule and at regular intervals: Loosen venting plug (9, Fig. 3-50:) and leave drain valve (3) open until there is no more water in the diesel fuel flowing out of the valve. Collect escaping liquid in a recipient suitable for diesel fuel and discard without polluting the environment.
Fig. 3-49:
Fig. 3-50:
The liquid flowing out of the valve flushes and cleans the filter element (6) von from top to bottom. Close drain valve (3) and tighten venting plug (9).
3-62
BA RH120E(3 725 097.01)-EN
