OPERATING INSTRUCTIONS 6030, 6030FS Inspection and servicing Replacing the oil filters Read and observe: "Inspection and servicing – Safety instructions".
Risk of scalding from hot engine oil. The filter housing may also be hot. Wear protective gloves and firm working clothing. Collect escaping oil and discard with-out polluting the environment.
Engine oil reservoir, filling in engine oil (oil grade see: “LUBRICANTS” section). The engine oil is filled in with the service station (Fig. 3-24:) through
express coupling (6) for the lefthand engine oil reservoir,
express coupling (7) for the righthand engine oil reservoir,
until the the corresponding pilot lamp (1 or 2, Fig. 3-24:) lights up.
Replacing oil filters Carry out servicing of the oil filters (1, Fig. 3-23:) in accordance with the engine operating instructions. Replacement: Shut off the engines. Unscrew the filters. Install new filter together with slightly oiled sealing ring and tighten by hand.
Unscrew cap of express coupling and connect hose line of the service vehicle. The hose line and its use are described in the "Hose line for oil and cooling liquid changes" section. Remove the hose line. The express coupling closes automatically. Screw on protective cap.
Thereafter Run engines at idling speed for a short time and check filters for leaks. Shut off engines. After 10 minutes check oil level, top up if neccessary. (oil grade see: “LUBRICANTS” section).
Fig. 3-24:
Fig. 3-23:
3-46
BA RH120E(3 725 097.01)-EN
