OPERATING INSTRUCTIONS 6030, 6030FS Inspection and servicing Draining the oil off the engine oil reservoir (optional) Read and observe: "Inspection and servicing – Safety instructions".
Risk of scalding from hot engine oil. The engines oil reservoirs may also be hot. Wear protective gloves and firm working clothing. Collect escaping oil and discard without polluting the environment
Drawing the oil off the engine oil reservoir (optional) Bring engine oil to operating temperature. Park the machine on a horizontal surface and secure engine oil reservoir Shut off the engines. Draw off engine oil with the service station (Fig. 3-22:) through
express coupling (6) for the lefthand engine oil reservoir
express coupling (7) for the righthand engine oil reservoir
Fig. 3-22:
The hose line and its use are described in the "hose line for oil and cooling liquid change" section. Remove the hose line. The express coupling closes automatically. Screw on protective cap. After the engine oil has been drawn off: Replace the oil filters.
Unscrew cap of epress coupling and connect hose line of the service vehicle
BA RH120E(3 725 097.01)-EN
3-45
