OPERATING INSTRUCTIONS 6030, 6030FS Inspection and servicing Filling in engine oil (oil grade see: “LUBRICANTS” section). Fill in engine oil through filler tube (2, Fig. 3-19:) until the oil level has reached the "max" mark (Fig. 3-20:) on dipstick (1, Fig. 3-19:).
Fig. 3-20:
Start the engines and allow to run at idling for abt. 2 minutes. Fig. 3-19:
Filling in engine oil through the service station (oil grade see: “LUBRICANTS” section).
Check oil level at dipstick (2, Fig. 3-19:) and top up with oil to the "max" mark (Fig. 3-20:) if required. Remove the filling hose. The express coupling closes automatically. Screw on protective cap.
Fill in engine oil through
express coupling (8, Fig. 3-21:) for the lefthand engine
express coupling (9) for the righthand engine
until the oil level has reached the "max." mark (Fig. 3-20:) on dipstick (1, Fig. 3-19:). Unscrew cap of express coupling and connect filling hose of the service vehicle. The hose line and its use are described in the "Hose line for oil and cooling liquid change" section. Fig. 3-21:
