OPERATING INSTRUCTIONS 6030, 6030FS Operation On-board crane, putting into operation Risk of serious injuries due to movements of the crane. Put the crane into operation only after all persons have left the danger area. Do not exceed the maximum lifting capacity (observe the lift capacity chart attached to the boom).
On-board crane, drive unit The drive unit (Fig. 2-131:) supplies the crane with hydraulic power. So the on-board crane is functional without the shovel’s engines running. The drive unit comprises the diesel engine, fuel tank, starter batteries and the hydraulic system. The drive unit is equipped with an Emergency OFF push switch (arrow, Fig. 2-131:). In case of emergency push switch, the engine of the drive unit comes to standstill.
Prior to each deployment: Carry out all maintenance work as listed in the “Inspection and Servicing Plans “T” and “W”. To start the drive unit: Turn key-switch (5, Fig. 2-131:) to position ON. Press button (6), engine will start. The crane control unit is equipped with an Emergency OFF push switch (11). In case of emergency push switch, the engine of the drive unit comes to standstill. After finishing work block the boom, then stop the engine (see chapter “On-board crane, - blocking the boom in position of rest”).
2-94
Fig. 2-131:
