OPERATING INSTRUCTIONS 6030, 6030FS Operation Shutting off the engines
Shutting off the left-hand engine
During interruptions of the work and after the work, stand working equipment on the ground. Do not shut off the engines before the working equipment rests on the ground.
Do not shut off the engine out of full load. The engine should be run at no more than one-half of the rated rpm for another 5 minutes to allow the lubricating oil and the cooling liquid to dissipate the combustion heat from the combustion chamber and from bearings and shafts. Reduce the speed of the engines to idling by pressing the left side of the speed adjusting switches (48, Fig. 2-95:) and (58, Fig. 2-96:). Press button (42, Fig. 2-95:) for the left-hand engine. The left-hand engine is stopped. Warning lamps (44 – 47) light up.
Fig. 2-95:
Shutting off the right-hand engine
Press button (52, Fig. 2-96:) for the right-hand engine. The left-hand engine is stopped. Warning lamps (54 – 57) light up. Switch off the electrical system with key-switch (32). Warning lamps (44 – 47, Fig. 2-95:) and (54 – 57, Fig. 2-96:) go out. The engines will be shut off with a delay of a few seconds. During this time, the current operating data are saved and the electronic units shut down.
Fig. 2-96:
