SPECIFICATIONS
Without dozer blade
Buckets
3.00 m
360 kg
2.50 m 2.10 m
1.50 m
3.00 m
4.50 m
6.00 m
7.50 m
4835* (1) 3580* (1)
2210*
1610
1160
420 kg
5450* (1) 4470* (1)
2370*
1620
-
450 kg
9995* (1) 4750* (1)
2500
1640
-
The loads given are valid for the total working range height at the reach point indicated.
With dozer blade
Dippers
Buckets
1.50 m
3.00 m
4.50 m
6.00 m
7.50 m
3.00 m
360 kg
-
3580* (1)
2210*
1700
1230
2.50 m
420 kg
-
4473* (1)
2365*
1710
-
2.10 m
450 kg
-
4980 (1)
2625
1725
-
The loads given are valid for the total working range height at the reach point indicated. IMPORTANT: For machines up to serial number DCH1300336, always attach the load to the connecting rod/bucket linkage pin when the values shown in these charts are followed by a (1). Never use the load handling eye on the bucket connecting rod for loads greater than 3000 kg (2941 daN). For machines with serial numbers DCH1300337 and above, use the load handling eye on the bucket connecting rod for all the values given. See “Load handling eye” in the “Controls/Instruments/ Accessories” Section.
213
