MAINTENANCE/ADJUSTMENTS STEP 4
STEP 3
Template Name: OM_1_col Template Date: 1994_04_29
1 1
2
2
PH08311
PH08307
Strike the front part (2) of the locking pin assembly and then alternately the rear (1) and front (2) parts until the assembly slots into the adaptor.
Check that the locking pin assembly (1) is in the right position. The front part (2) of the assembly should be fully engaged in the adaptor nose.
TEETH AND TOOTH TIP WEAR LIMITS TRIM THIS EDGE
NOTE: Do not wait for teeth or tooth tips to be completely worn through before changing them. IMPORTANT: Never try to work with a missing tooth tip or a tooth tip which is worn through. The adaptor could be seriously damaged.
Alt= to hide template information Alt+ to display template information
PH08307
The degree to which teeth or tooth tips are worn can be assessed visually. It is possible to extend the life of teeth or tooth tips which are wearing unevenly, in a non-symmetrical fashion. Interchange and turn over the teeth regularly. Turn over the locking pin too.
