Chapter 4
OPERATING INSTRUCTIONS BEFORE STARTING THE ENGINE Check the machine each morning before beginning work. For general maintenance of the machine, follow the Lubrication and Maintenance Chart, on page 110. 1
1. Check if the tires are worn, cut or not properly inflated. 2. Check if the blade, cutting edges and bits are worn or damaged. 3. Check circle adjustment. 4. Check for damaged or failed instruments and other operator’s compartment components.
3
5. Check leakage on tandem case.
2
6. Check any leakage or damage to cooling system hoses. 7. Check engine oil and hydraulic lines and hoses for leaks. It’s also recommended to check
4
Electrical system Bolts
Hydraulic system 5
Lubrication
Check insulation parts, worn cables and terminals loose
Check for loose or missing parts Check leakages, twisted hoses, hoses rubbing against other components Check all grease points related on periodic maintenance table
8. Fill the fuel tank only with the specified fuel. Take care to avoid entrance of dirt or foreign matter while filling tank.
7 6
WARNING: Extinguish all smoking materials or open flames before checking and/or filling the fuel tank. 9. Check the fluid levels of the following: a. Engine crankcase b. Engine cooling system c. Transmission system d. Hydraulic system e. Axle housing and rear tandem housings.
83
