CHAPTER 3 – INSTRUMENTS AND CONTROLS
Air Conditioning, Heating and Air Circulating System Air Conditioning Control
2
3. Recirculation / Fresh Air Selector (Optional): Turn the selector to position “ ” to recirculate the air inside the cabin. Turn the selector to position “ ” to allow the fresh air entrance inside the cabin
3
4
4. Temperature Control Selector (Optional): 1
Turn the temperature control selector counterclockwise to obtain cold air inside the cabin. Turn the temperature control selector clockwise to obtain hot air inside the cabin. Adjust the temperature control selector and the ventilation selector to the desired positions, to obtain maximum thermal comfort. Make sure the heater water input is totally open when desiring to obtain hot air in the cabin. Maintenance
1. 2. 3. 4.
On / Off Switch (Optional) Ventilation Selector (Optional) Recirculation / Fresh Air Selector (Optional) Temperature Control Selector (Optional)
The air conditioning and heating system maintenance is limited to three components: a. Evaporation case air filter. b. Air compressor c. Condenser
1. On / Off Switch (Optional) Press this switch and select one of the 3 ventilation speeds in order to activate the air conditioning system. Press again this switch to turn off the air conditioning system. When the system is running, a blue light on the switch will turn on. 2. Ventilation Selector (Optional): The ventilation selector has 4 positions: OFF and speeds 1, 2 and 3. Turn the selector to positiono “ ” to obtain maximum speed ventilation and to position “ ” to obtain minimum speed ventilation. When the selector is turned to OFF position, the air conditioning system is turned off automatically
EVAPORATION CASE AIR FILTER
The evaporation case air filter cleaning must be performed whenever necessary or every 250 hours.
73
