CHAPTER 6 – LUBRICATION / FILTERS / FLUIDS
Hydraulic Tank and Engine Fuel Filter Each 50 hours services
Hydraulic Tank
Fuel Filter Draining
WARNING: Fluid under pressure. Turn the cap (2) slowly to relieve the pressure, before removing. Be sure the machine is on level ground with the engine off. Lower the moldboard to the ground. Check the oil level through sight gauge (1). The oil level should be at the center of the gauge. If necessary, remove the hydraulic tank filler cap (2) and add oil.
Open the drain cock located on the bottom of the filter to remove the accumulated water. Important: The drain cock is made of plastic material. Do not over tighten when closing.
845B Models
1
3
2 1 1. Water separator and fuel filter 2. Drain cock 3. In line fuel filter 1. Oil level gauge
865B AND 885B Models
2 1
2
2. Hydraulic tank filler cap
1. Water separator and fuel filter 2. Drain cock
115
