A
REAR MAIN OIL SEAL Removal and Installation The crankshaft is fitted with a lip type rear oil seal and has a mounting flange with an extended width to provide a seat for the seal. This seal is easily damaged and you must be careful not to damage it. Any visual damage across the lip of the seal will cause leakage.
1/4’’ (6,4 mm) 1/8’’ (3,2 mm)
When installing a new seal, check the crankshaft flange, and if it is found to be grooved, the seal must be pressed further into the housing [A]. Lubricate both the seal and the housing when installing the seal.
