Removing the Optical Drive Module 1. See “Removing the Battery Pack” on page 42. 2. Remove the screw securing the ODD module.
Step ODD Module
Size M2.5*8
Quantity
Screw Type
1
3. Insert a suitable tool into the access slot in the battery bay as shown. Gently lever the ODD module out of the chassis. 4. Pull the optical drive module out from the chassis.
Chapter 3
45
