DOS Flash Utility Perform the following steps to use the DOS Flash Utility: 1.
Press F2 during boot to enter the Setup Menu.
2.
Select Boot Menu to modify the boot priority order, for example, if using USB HDD to Update BIOS, move USB HDD to position 1.
Information
Main
PhoenixBIOS Setup Utility Security Boot Exit Item Specific Help
Boot priority order: 1: IDE0: ST960821A 2: IDE1: MATSHITADVD 3: USB FDD: 4: Network boot: Realtek Boot Agent 5: USB HDD: xxxx USB 6: USB CDROM:
F1 Help Es c Exit 3.
Select Item Select Menu
F5/F6 Enter
Use < > or < > to select a device, then press <F6> to move it up the List, or <F5> to move it down the list. Press <Esc> to escape the menu.
C h a n g e Va l u e s Select Sub-Menu
F9 F10
Setup Defaults Save and Exit
Execute the FLASH.BAT batch file to update BIOS in DOS mode.
The flash process begins as shown.
32
Chapter 2
