Removing the Power Board 1. Remove the Keyboard. See “Removing the Keyboard” on page 59. 2. Unlock the FFC connector and remove the FFC.
3. Remove the single securing screw.
Step Power Board
Size M2*3
Quantity
Screw Type
1
4. Using your finger lift the bottom side of the Power Board to remove.
Chapter 3
65
