Removing the LED Board 1. Remove the Keyboard. See “Removing the Keyboard” on page 59. 2. Unlock the FFC connector and remove the FFC.
3. Remove the single securing screw.
Step LED Board
Size M2*3
Quantity
Screw Type
1
4. Grasp the top side of the LED Board and pivot upwards to remove.
