Removing the Optical Drive Module 1. See “Removing the Battery Pack” on page 44. 2. Loosen the screw to remove the ODD cap. 3. Remove the single securing screw.
Step ODD Module
Size M2.5*8
Quantity
Screw Type
1
4. Using a screw driver, push the ODD module and grasp the front panel to remove from the computer.
52
Chapter 3
