Removing the LCD Panel 1. Remove the LCD Bezel. See “Removing the LCD Bezel” on page 88. 2. Remove the two securing screws from the LCD Module. IMPORTANT:The correct screw sockets are indicated by a mark on the hinge.
Step LCD Panel
Size M2.5*4
Quantity
Screw Type
2
3. Grasp the LCD Panel by the hinges and tilt upwards and away to remove the LCD Module.
94
Chapter 3
