Technical data T-code 795
Valid from serial number 904526-
Model
Date 2006-04-10
Order number 235568-040
SP10
SP10S
Drive wheel
Ø250x60 mm
Ø250x60 mm
Axle pressure without load
210 kg
440 kg
Axle pressure at rated load
360 kg
580 kg
Tightening torque for wheel bolts
20 Nm
20 Nm
Fork wheels
Ø85 mm
Ø85 mm
Axle pressure without load
2x60 kg
2x80 kg
Axle pressure at rated load
2x500 kg
2x515 kg
Support arm wheels
Ø100x40 mm
-
Axle pressure without load
2x70 kg
-
Axle pressure at rated load
2x70 kg
-
Output
1,4 kW
1,4 kW
Duty cycle
3,5 %
3,5 %
Minimum carbon brush length
10 mm
10 mm
Minimum commutator thickness/diameter
28,6 mm
28,6 mm
Pressure at rated load
190 bar
190 bar
Overflow pressure
210 bar
210 bar
Pump flow
4,5 l/min
4,15 l/min
Tank volume
2l
2l
Oil type at normal temperature
ISO-L-HM32
ISO-L-HM32
Oil type <15 °C
ISO-L-HV32
ISO-L-HV32
Drive motor circuit (shared with pump)
100 A
100 A
Pump motor circuit (shared with drive motor)
100 A
100 A
Control circuits
5A
5A
Battery charger
10 A
10 A
Dimension L x W x H
278x175x190 mm
278x175x190 mm
Capacity
50 Ah
50 Ah
Weight
2x20 kg
2x20 kg
Wheels
Hydraulic system
Fuses
Battery compartment, Batteries
2- 2
Service Manual
SP10, SP10S
