Electrical systems – 5000 Parameters Order number 222996-040
Date 2005-11-04
Valid from serial number 723984-
T-code 497
13.6.3 Service parameters • • • •
A
E
D
C
B
Connect CAN-key in X41 Press S18 and turn S17 to on at the same time. Press S18 until you read P= parameters. You have now choosen P=parameters the symbol “C” on display will be highlighted to indicate what’s currently shown on display. • Scroll to the parameter you want to change or look at by pressing the L1 up or down. • Press S18 ones to get access to the parameter. • Set parameter value by pressing L1 up or down. • Press S18 ones to confirm change. • Turn S17 to off. You have now completed a parameter change and the next time you start the truck the new parameter setting will be valid. NOTE ! Truck handling. Modifying specific truck parameters will change the driving characteristics of the truck. Do not change any parameters without the necesarry know-how.
Parameter
Description
10
Min .
Max .
Step
Std .
Description
PIN-code
0
9999
1
1
Facility for specifying up to 10 PIN codes (10 different drivers).
14
Crawling speed
-10
10
1
0
The amount of power the monitor should emit when you reach the first speed sensor can be specified here. -10: low speed for the first speed sensor. 10: high speed for the first speed sensor
15
Non-configurable option 0 to 9
See “Option parameters” on page 29
16
Configurable option #1
See “Option parameters” on page 29
17
Configurable option #2
18
Configurable option #3
19
Configurable option #4
© TIEE SARL
Unit
Service Manual
7PLL24
13- 27
