Electrical systems – 5000 Parameters Order number 222996-040
Date 2005-11-04
Valid from serial number 723984-
T-code 497
13.6 Parameters A
E
D
C
B
• Press S18 and turn S17 to on at the same time. • Press S18 until you read P= parameters. • You have now choosen P=parameters the symbol “C” on display will be highlighted to indicate what’s currently shown on display. • Scroll to the parameter you want to change or look at by pressing the L1 up or down. • Press S18 ones to get access to the parameter. • Set parameter value by pressing L1 up or down. • Press S18 ones to confirm change. • Turn S17 to off. You have now completed a parameter change and the next time you start the truck the new parameter setting will be valid. NOTE ! Truck handling. Modifying specific truck parameters will change the driving characteristics of the truck. Do not change any parameters without the necesarry know-how.
13.6.1 Driver parameters Parameter
Name
Unit
Min
Max
Step
Std
Description
1
Speed, low Speed
%
10
100
5
100
10:low Speed 100:highest Speed
02
Speed, high speed
%
10
100
5
100
10:low Speed 100:highest Speed.
03
Acceleration
10
100
5
75
10:low acceleration 100:full acceleration
04
Neutral speed reduction
5
100
5
80
Defines motor speed reduction force when lever goes to neutral position. 5: low reduction force 100: full reduction force
05
Logout
0
20
1
20
The time it takes for the truck to switch off when the keypad is used. The time counts down from the moment the last power-consuming unit is used. Value = 0 gives 4 hours. In steps of 1
© TIEE SARL
1min
Service Manual
7PLL24
13- 25
