Electrical systems – 5000 Functional description T-code 497
Valid from serial number 723984-
Date 2005-11-04
Order number 222996-040
13.3.6 Neutral speed reduction on slopes If the driver release the speed leaver (L1) on a slope and the truck doesn’t come to a stop within a certain time the electrical brake will be applied.
13.3.7 Braking The brake is always applied when the truck is started with the tiller arm in it’s upper or lower position (S10 open). The brake is released in the same moment as the conditions for driving are fulfilled and the truck starts to move. Conditions to brake the truck: • S10 open or S19 open.
13.3.8 Lifting the forks • S34 activated. • S31 closed. • Battery status ok (if battery capacity >20% left).
13.3.9 Lowering the forks • S41activated.
13.3.10 Horn • S18 activated.
13- 12
Service Manual
7PLL24
© TIEE SARL
