Preventive maintenance – P2 Maintenance schedule T-code 497
Valid from serial number 723984-
Date 2005-11-04
Order number 222996-040
I: Inspect, correct and replace if necessary. T: Tighten C: Clean L: Lubricate M: Measure, correct if necessary
Pos. no.
Work to carry out Interval in hours - may vary due to application
5
20
500
1000
3000
Interval in days/weeks/months - may vary due to application
1d 1w 6m
12m
36m
3100
Brakes
3100.1
Clean
3100.2
Check for wear to the brake discs
M
3100.3
Check for play in released position
M
3500.
Wheels
3500.1
Remove string and other detritus
3500.2
Check for wear on the drive wheel
I
3500.3
Check that the swivel wheels rotate and swing freely
I
3500.4
Check for wear to the swivel wheels
I
4110.
Tiller arm
4110.1
Check for play on steering joints
I
4110.2
Check the steering force
I
4110.3
Check the gas cartridge's force
4110.4
Check the adjustment of the steering chain, lubricate
5000.
Electrical functions
5000.1
Check the operation of the brake microswitch in the upper and lower brake positions. Lubricate the switch head
I
5000.2
Check the function of the safety switch against collision
I
5000.3
Check the operation of the gate switch
I
I
5000.4
Check the operation of the platform switch
I
I
5000.5
Check the horn
I
I
5000.6
Check for wear to the cables
5000.7
Check the operation of the driver's controls
I
I
5000.8
Check the error code log and operatingtimes
I
I
4- 2
C
Service Manual
I
I L/M I/L
I
7PLL24
