Installation and maintenance instructions – P1 Introduction, maintenance Order number 222996-040
Date 2005-11-04
Valid from serial number 723984-
T-code 497
3.2 Introduction, maintenance All points in the service program shall be included to attain the highest safety and a least possible truck downtime. The service intervals are only a guide and do not need to be followed strictly. The truck driver must adapt these to local conditions, but it is important that the intervals meet TOYOTA's minimum demands. The service intervals are based on operating times and can be adapted to most normal 8 hour shifts. The following operating hours have be used when calculating the interval. Day time:
08.00-17.00 (20 hours/week)
2-shifts:
06.00-14.00, 14.00-22.00 (40 hours/week)
3-shifts:
06.00-14.00, 14.00-22.00, 22.00-06.00 (60 hours/week)
Ensure the truck is given regular maintenance services according to the maintenance schedule. The truck's safety, efficiency and service life is dependent on the service and maintenance it is given. Only use TOYOTA approved spare parts during service and repairs
3.2.1 Safety regulations during maintenance work Only persons trained in servicing and the repair of this type of truck are qualified to carry out service and repair work. • Do not carry out any maintenance work on the truck if you do not have the right qualifications and know how to carry out the work. • Keep the area where service work is done clean. Oil or water will make the floor slippery. • Never wear loose objects or jewellery when working on the truck. WARNING! short-circuit/Burns short-circuiting and burn injuries can occur if metal objects come into contact with live electrical connections, when working on the truck's electrical system. Remove watches, rings and other metal jewellery.
• Always remove the battery plug when carrying out maintenance on the truck, if the instructions in this service manual do not say otherwise. • Always switch off the truck's power supply before the hoods to the drive assembly and the electrical system are opened. • Offload the system pressure slowly before work on the truck's hydraulic system is started. • Use paper or rigid cardboard when checking a possible oil leakage. Never use your hands.
© TIEE SARL
Service Manual
7PLL24
3- 5
