PowerTrak cylinder – 6680 Dismantling the PowerTrak cylinder T-code 497
Valid from serial number 723984-
Date 2005-11-04
Order number 222996-040
15.2 Dismantling the PowerTrak cylinder
1 2 4
Make sure the truck is unloaded and the forks lowered. • Switch off the truck and remove the battery plug. • Dismantle the gate console and drive motor.
3
• Loosen the hydraulic hose using a 19 mm spanner (1). • Unscrew the hydraulic connection from the cylinder with a 27 mm spanner (2). Counter hold the cylinder's piston with a 22 mm spanner. • Unscrew both guide screws with a 6 mm allen key and a 13 mm spanner (3). • Remove the circlip (4). • Lift up the truck so that the drive wheel is free from the ground using a jack or the like. Block up the truck so that it is stable. • Press down the cylinder so that the PowerTrak cylinder and spring can be removed. When the piston is pressed down oil can squirt out from the piston. Assemble in the reverse order.
100
Measurement between the washer and bolt head, 100 mm. WARNING! Risk of injury There is a risk of personal injury in connection with working on the PowerTrak system. Follow the instructions carefully.
15- 2
