Hydraulic, pneumatic – 6000 Adjustments Order number 222996-040
Date 2005-11-04
Valid from serial number 723984-
T-code 497
14.2 Adjustments 14.2.1 Adjustment of the pressure limit valve The pressure limit valve is set to the correct value at the factory, but may need to be adjusted if the valve or complete hydraulic unit is replaced. The truck should be able to lift a load of between 2250-2300 kg.
Pos.
Description
1
Cover nut
2
Adjuster screw, pressure limit
Notes Adjustment clockwise results in increased pressure Adjustment anticlockwise results in reduced pressure
• Unscrew the cover nut (1) with a spanner, 13 mm. • Place a load, 2200 kg, on the forks and check that the machine lifts this. • If the machine can lift 2200 kg, place a further 100 kg on the forks. Check whether machine can lift the load. • If the machine can lift 2300 kg, adjust the pressure limit valve by screwing the adjuster screw (2) anticlockwise using a 4 mm allen key until the machine cannot lift the load.
© TIEE SARL
Service Manual
7PLL24
14- 3
