Electrical systems – 5000 Parameters Order number 222996-040
Date 2005-11-04
Valid from serial number 723984-
T-code 497
Parameter 39 Login method and driver parameter access This parameter determines which function is to be used for login and whether the operator can adjust the driver parameter settings. • Value 1 – Key switch fitted – Driver parameters accessible (without CAN service key). • Value 2 – Key switch fitted – Driver parameters NOT accessible (without CAN service key). • Value 3 – Keypad (Standard 10 PIN code)- Driver parameters accessible (without CAN service key) NB! this is the original setting. • Value 4 – Keypad (Standard 10 PIN code)- Driver parameters NOT accessible (without CAN service key). • Value 5 – Expanded keypad (100 PIN code)- Driver parameters accessible (without CAN service key) • Value 6 – Expanded keypad (100 PIN code)- Driver parameters NOT accessible (without CAN service key) • Value 7 – Expanded keypad (100 PIN code) + TLS- Driver parameters accessible (without CAN service key) • Value 8 – Expanded keypad (100 PIN code) + TLS- Driver parameters NOT accessible (without CAN service key)
Expanded keypad - General The truck can contain a maximum of 10 individual driver profiles. The expanded keypad function thus allows you to assign a maximum of 10 PIN codes for each of the driver profiles. This allows you to manage a maximum of 100 unique PIN codes. If the expanded keypad function is activated, the standard management of PIN codes normally accessible via parameter #10 is set aside.
Expanded keypad - Programming A number of PIN codes can be made accessible by activating the socalled block. Block no. 0 is activated as standard. This means that 3 different driver profiles are available from the start. Activation of other blocks means that all PIN codes for the block are accessible (See Table 5:). If all 10 blocks are activated, there will be 10 PIN codes available for the driver profile. The truck program stores a standard list of PIN codes as per Table 5: These PIN codes can be changed to any value, but you should avoid the same PIN code in different driver profiles.
© TIEE SARL
Service Manual
7PLL24
13- 41
