Electrical systems – 5000 Parameters T-code 497
Valid from serial number 723984-
Date 2005-11-04
Order number 222996-040
Instructions for verifying parameter setting • Charge up the battery • Use the truck in its normal application until the battery indicator shows an empty battery (0% on the display). • Disconnect the battery from the truck and allow the battery to rest for at least two hours. NB! No charging or discharging during this period. • Measure the battery voltage at room temperature. If the voltage is less than Uend, see the table below, the parameter value must be reduced. If the value significantly exceeds Uend, the risk of damage to the battery is reduced. At the same time, the operating time of the truck is reduced. If a longer operating time is required, the parameter value can be increased. Maximum one unit. • Each change must be accompanied by a new verification of the parameter setting.
Battery type
Battery voltage at rest, Uend
Hawker Evolution
24,24 V
Parameter 22 You must specify the type of brake switch the truck is equipped with. Mechanical switch = 0 Inductive sensor= 1
Parameter 25 Using this parameter you can specify a limit for when the next service is to take place, from 0 to 2000 hours, in 50-hour steps. When it is time for a service, warning 29 (C29) is shown in the display.
Parameter 28 Using this parameter you can select which button is to be used for lift/ lower. 1 = Bottom lift/lower button activated (default) 2 = Top lift/lower button activated 3 = Both lift/lower buttons are activated
13- 40
Service Manual
7PLL24
